Procraft 5/8″ 3.25T Screw Pin Shackle

Home/SALE!, Shackle/Procraft 5/8″ 3.25T Screw Pin Shackle

Procraft 5/8″ 3.25T Screw Pin Shackle

USD $ 7.54 USD $ 6.03

In stock

The Profraft 5/8″ 3.25T Screw Pin shackles are a great, affordable, all around industrial shackle.  The screw pin is the most common type of shackle due to its ease of use but does have some disadvantages to the bolt style shackle.  Load Rated Screw Pin Anchor (SPA) Shackles are hot dipped galvanized and meet or exceeds US Fed Spec RRC-271 Type IVA Class 2 Grade A.

NOTE

In stock

SKU: SHKL-PRCRFT-58 Categories: ,

Description

The Profraft 5/8″ 3.25T Screw Pin shackles are a great, affordable, all around industrial shackle.  The screw pin is the most common type of shackle due to its ease of use.  Load Rated Screw Pin Anchor (SPA) Shackles are hot dipped galvanized and meet or exceeds US Fed Spec RRC-271 Type IVA Class 2 Grade A.  Screw pin shackles can be used for static line lock off, connections to pullies, rigging plates and are big enough to fit the largest of anchor points.

DO NOT use screw pin shackles or put the pin in contact with moving parts as there is a risk of the pin opening.

WARNING – Be careful when using the screw pin shackles for a line locker.   While screwing the pin, there is a risk that the webbing may become caught in the threads, potentially damaging the webbing.

Specifications

  • Working Load Limit:  3-1/4 Tons
  • Pin Diameter:  3/4″
  • Inside Length:  2-3/8″
  • Inside Width at Pin:  1-1/16″
  • Weight:  0.76kg
